Fargo HDP5000e Single-Side Lamination Module

Upgrade your card printing system with the Fargo HDP5000e Single-Side Lamination Module, designed to deliver robust protection and extended card life for high-use credentials. Built exclusively for the HDP5000e printer series, this modular enhancement applies a single-sided laminate layer to each card, reinforcing its resistance to wear, fading, and tampering.

• Precision Overlamination: – Applies a thermal transfer film or PolyGuard™ overlaminate in thicknesses of 0.25 mil, 0.6 mil, or 1.0 mil for added strength and security.
• Visual Security Options: – Supports both clear and holographic designs to match your brand or meet your anti-counterfeit requirements.
• Fast Adjustable Performance: – Lamination speeds range from 0.8 to 5.5 seconds per inch, allowing you to balance speed with quality.
• Plug-and-Play Integration: – Draws power and communication directly from the HDP5000e main unit—no external power source needed.
• Effortless Installation: – Field-upgradeable with no tools required, so you can enhance your printer in minutes.

Compatibility Notice: This module is specifically engineered for the HDP5000e and is not compatible with HDP5000 or HDP5600 models.

Supported Card Types: CR-80 cards (30–50 mil) made of Composite PVC, PETG, or Polycarbonate. (Standard PVC cards are not recommended.)

Technical Specifications:

• Dimensions: 12.75" W x 12.25" H x 11.0" D (324mm x 313mm x 280mm)
• Weight: Approx. 6.5 lbs (3 kg)
• Power Interface: Powered through the HDP5000e printer via internal interface
• Warranty: 4 Years (when using HID FARGO-certified materials)

Whether you're issuing secure employee badges, access cards, or government credentials, the Fargo HDP5000e Lamination Module ensures every card meets the highest standards of durability and tamper resistance.
